Product Characteristics
Επικάλυψη
Blue
Υλικό
Καρβίδιο
The YG-1 G8A01 series X5070 Blue ultrafine micrograin carbide cutter has 2 flutes and a plain shank. These slot drills have an extended/relieved neck and range in diameter from 0.1mm-20mm. The X5070 range is designed for ultra-performance machining of steels, heat resistant steels and hardened steels up to HRc70. The nanograin substrate and silicone based coating allows for dry machining up to temperatures of 1400°c.
- Nanograin carbide substrate with blue silicone based coating.
- Dry machining in steels and hardened steeld < HRc70.
- Suitable for machining at extreme cutting speeds.
- High abrasion resistance with a mirror surface finish.
- Strong negative land provides tool strength for high hardness machining.
- Ultimate tool life.
- Can cope with extreme heat (up to 1400°)
- Long neck for extended reach.
- To achieve the maximum performance from this tool, we recommend using a high performance tool holder (Hydraulic chuck, shrink chuck, HP3/GSK or power milling chuck).
Quote
| SKU | D1 (mm) | D2 - D3 (mm) | L2 - L1 - L3 (mm) | Availability |
Price
+VAT
|
Cart
Quote
|
|---|---|---|---|---|---|---|
| ET2BLUE-0.1 | 0.1 | 4 | 40 - 0.2 | On Order |
+VAT
€63,00
|
|
| ET2BLUE-0.2 | 0.2 | 4 | 40 - 0.4 | 5-8 business days |
+VAT
€42,10
|
|
| ET2BLUE-0.3 | 0.3 | 4 | 40 - 0.6 | 5-8 business days |
+VAT
€36,40
|
|
| ET2BLUE-0.4 | 0.4 | 4 | 40 - 0.8 | 5-8 business days |
+VAT
€39,70
|
|
| ET2BLUE-0.5 | 0.5 | 4 | 40 - 1 | 5-8 business days |
+VAT
€28,70
|
|
| ET2BLUE-0.6 | 0.6 | 4 | 40 - 1.2 | 5-8 business days |
+VAT
€30,20
|
|
| ET2BLUE-0.7 | 0.7 | 4 | 40 - 1.4 | 5-8 business days |
+VAT
€34,50
|
|
| ET2BLUE-0.8 | 0.8 | 4 | 40 - 1.6 | 5-8 business days |
+VAT
€33,60
|
|
| ET2BLUE-0.9 | 0.9 | 4 | 40 - 2 | On Order |
+VAT
€33,60
|
|
| ET2BLUE-1 | 1 | 6 - 1.95 | 50 - 1.5 - 3 | 5-8 business days |
+VAT
€38,20
|
|
| ET2BLUE-1.5 | 1.5 | 6 - 1.95 | 50 - 1.7 - 4 | 5-8 business days |
+VAT
€38,20
|
|
| ET2BLUE-2 | 2 | 6 - 1.95 | 50 - 2 - 5 | 5-8 business days |
+VAT
€38,20
|
|
| ET2BLUE-2.5 | 2.5 | 6 - 2.40 | 55 - 2.5 - 6 | 5-8 business days |
+VAT
€38,20
|
|
| ET2BLUE-3 | 3 | 6 - 2.85 | 55 - 3 - 8 | 5-8 business days |
+VAT
€38,20
|
|
| ET2BLUE-3.5 | 3.5 | 6 - 3.35 | 55 - 3.5 - 9 | 5-8 business days |
+VAT
€38,20
|
|
| ET2BLUE-4 | 4 | 6 - 3.85 | 55 - 4 - 10 | 5-8 business days |
+VAT
€38,20
|
|
| ET2BLUE-5 | 5 | 6 - 4.85 | 55 - 5 - 13 | 5-8 business days |
+VAT
€38,20
|
|
| ET2BLUE-6 | 6 | 6 - 5.85 | 55 - 6 - 15 | 5-8 business days |
+VAT
€38,20
|
|
| ET2BLUE-8 | 8 | 8 - 7.70 | 65 - 8 - 20 | 5-8 business days |
+VAT
€47,00
|
|
| ET2BLUE-10 | 10 | 10 - 9.70 | 75 - 10 - 25 | 5-8 business days |
+VAT
€70,00
|
|
| ET2BLUE-12 | 12 | 12 - 11.70 | 85 - 12 - 28 | 5-8 business days |
+VAT
€98,00
|
|
| ET2BLUE-16 | 16 | 16 - 15.70 | 90 - 16 - 32 | 5-8 business days |
+VAT
€163,00
|
|
| ET2BLUE-20 | 20 | 20 - 19.70 | 105 - 20 - 40 | On Order |
+VAT
€269,00
|
