MG-25B-100D-1/2-D-MAX-CL1-FIN - Glycerin Pressure Gauge Ø100 mm 0-25 bar 1/2"" Bottom Thread Maximum - class1 - full inox
| Κωδικός | Diameter | Bar | Thread | Τιμή | Στοκ | ||
|---|---|---|---|---|---|---|---|
| MG-B25-D100-D1/2-CL1.0-MAX-INOX | Ø100 mm | 25 Bar | 1/2" | €96,00 | 1 διαθέσιμo | ||
Τιμές χωρίς ΦΠΑ 24%
Applications
- For measuring points with high dynamic pressure loads or vibrations
- For gaseous and liquid media that are not highly viscous or crystallized and do not attack copper alloy parts
- Hydraulic principle of operation
- Compressors
Special characteristics
- Shock resistant
- Robust design
- Stainless steel case containing liquid
- The scale ranges up to 0 ... 600 bar
Standards:
Nominal size in mm
40, 80, 100
Accuracy class
2.5
Scale range
NS 40: 0 ... 1 to 0 ... 400 bar
NS 80, 100: 0 ... 1 to 0 ... 600 bar
or all other equivalent areas of vacuum or combined pressure and vacuum
Pressure limitation
Fixed: 3/4 x full scale value
Floating: 2/3 x full scale value
Short time: Full scale price
Permissible temperature
Environment: -20 ... +60 °C
Medium: +60 °C max
Effect of temperature
When the temperature of the measuring system deviates from the reference temperature (+20 °C): maximum ±0.4 %/10 K of the range
Sealing class
IP 65 (Waterproof) per EN 60529 / lEC 60529
Plan EN 837-1
