Anemometer Sensor
| Κωδικός | Output Signal | Τιμή | Στοκ | ||
|---|---|---|---|---|---|
| PCE-FST-200-201-U | 0-10V | €240,00 | Κ.Π. 5-8 εργάσιμες * | ||
| PCE-FST-200-201-I | 4-20mA | €271,00 | 1 διαθέσιμo | ||
* Κ.Π. : Κατόπιν Παραγγελίας
Τιμές χωρίς ΦΠΑ 24%
| Output signal | 4 … 20-mA |
| Operating voltage | 12 … 36V DC |
| Measurement range | 0.5 m/s ... 50 m/s (1.1 ... 111.8 mph) |
| Measure from | ≤ 0.5 m/s (1.1 mph) |
| Measurement accuracy |
± 0.5 m/s (1.1 mph), (< 5 m/s (11.2 mph)) ± 3% of full scale value |
| Heat generation | 10 W at 24 V DC |
| Operating temperature range | -20 ... 185°C / -4 ... 85°F, at ≤ 95% RH |
| Maximum wind speed | 70 m/s (156.6 mph) at 30 minutes maximum |
| Power connection | M12 |
| Protection class | IP 55 |
Durable wind speed measurement sensor PCE-FST-200-201-I for permanent installation /
Waterproof sealing protection
The wind speed sensor is compatible with a wide variety of measuring devices. The sensor detects even the smallest air movements from 0.5 m/sec and then the measurement data is exported in analog form. The sensor is made of a corrosion resistant alloy thus making it impervious to oxidation or rust. This allows the device to be used in the most demanding environments. Hazardous parts are sealed to prevent water or fine dust from entering.
The wind speed sensor is available in different versions with different outputs. This is available with a current output of 4 … 20 mA and a voltage output of 0 … 10 V DC.
- Made of alloy
- Long lifespan
- Sealing protection
- Analog output signal
- Easy assembly
- Detects the smallest air movements
- Long lifespan
- Sealing protection
- Analog output signal
- Easy assembly
- Detects the smallest air movements
1 x Glider Sensor PCE-FST-200-201-I
1 x M12 Plug
1 x 3 m / 9.8 ft cable
1 x M12 Plug
1 x 3 m / 9.8 ft cable
1 x User Manual
