Photometer - 400,000 lux (includes software)
PCE-LMD 10
| Measuring range (lux) | 1000 ... 400,000 lux |
| 0.0 ... 999.9 lux | |
| Reading | 1 lux (for 1000...400,000 lux) |
| 0.1 lux (for 0.0 ... 999.9 lux) | |
| Measurement range (footcandle) | 1000 ... 400,000 fc |
| 100 ... 999 fc | |
| 0.00 ... 99.00 fc | |
| Reading | 1 fc (for 1000 ... 400,000 fc) |
| 1 fc (for 100 ... 999 fc) | |
| 0.01 fc (for 0.00 ... 99.00 fc) | |
| Accuracy | ±5 % of the measured value ±10 digits with standard A light |
| ±10 % of the measured value ±10 digits | |
| Repeatability | ±2 % |
| Sampling rate | 4 Hz |
| Peak Hold | 10 µs |
| Sensor | silicon photodiode with spectral filter |
| Battery status | battery symbol appears when the voltage is low |
| Exit | Micro-USB (charging only) |
| Memory | 32000 records |
|
Power battery |
Li-Ion Battery 3.7 V |
| USB power supply | 5 V DC, 1 A |
| Operating conditions | -10 … 50 °C / 14 ... 122 °F / <80 % RH, |
| no condensation | |
| Storage conditions | -20 … 50 °C / -4 ... 122 °F / <80 % RH, |
| no condensation | |
| Dimensions | meter: 162 x 88 x 32 mm / 6.4 x 3.5 x 1.3" |
| sensor: 102 x 60 x 25 mm / 4 x 2.4 x 1" | |
| Weight | ~320 g / 11.3 oz |
Light meter with external sensor / Sampling rate 4 Hz / Measurement range 0 ... 400 kLux / Micro-USB / Units: lux, footcandle / Optional with ISO calibration certificate
The light meter has a wide measurement range of 0 … 400 klux. Illumination is measured using an external silicon photodiode with spectral filter. in lux and footcandles. The measured value is displayed on the photometer screen both numerically and graphically. The measured value can be compared with a reference value by pressing the "REL" button. The photometer also features maximum and minimum value measurement functions, which are displayed on the screen by pressing the corresponding "MAX" and "MIN" buttons. With the "PEAK" function, the photometer records the maximum light values it detects at a sampling rate of 1 per 10 µs.
The PCE-LMD 10 has a memory of 32000 records. These data can be exported in csv format for further analysis and processing on a computer.
Measurement can also be taken live via computer.
The built-in 3.7 V Li-Ion battery can be recharged via 5V DC voltage through micro-USB. Optional ISO calibration certificate is available.
- Rechargeable battery
- Micro USB port
- Measurement range 0 ... 400000 lux
- Units Lux and footcandle
- Illuminated LCD display
- Optional with ISO calibration certificate
Package contents
1 x Light Meter PCE-LMD 5
1 x USB cable
1 x USB cable
1x PC software
1 x bag
1 x Instruction manual
1 x bag
1 x Instruction manual
