Vibration Sensor Horizontal 12.7 mm/s 1500Hz
| Κωδικός | Τιμή | Στοκ | |
|---|---|---|---|
| PCE-PVS 30 | €648,00 | Κ.Π. 5-8 εργάσιμες * |
* Κ.Π. : Κατόπιν Παραγγελίας
Τιμές χωρίς ΦΠΑ 24%
|
Acceleration Sensor for monitoring the vibration speed / 4 ... 20 mA output
MIL-C-5015 connection / 3 ... 1500 Hz bandwidth
The Acceleration Sensor has been developed for the continuous monitoring of the vibration speed. The Acceleration Sensor is available in different versions. Depending on the type of vibration sensor, a distinction is made between design and measuring range. The Acceleration Sensor measures the vibration speed in the range of ± 12.7 mm / s or ± 25.4 mm / s in the frequency range between 3 Hz and 1500 kHz.
The measured vibration speed is output as a 4 ... 20 mA process current. The Acceleration Sensor is looped through a MIL-C-5015 connector to a controller or process display. Depending on the design, the connection socket is attached to the vibration sensor vertically or horizontally. The Acceleration Sensor can be operated with a voltage of 12 ... 24 V DC.
- horizontal or vertical installation
- Process signal output
- MIL-C-5015 connector
- M6 process connection
- different measuring ranges
- robust construction
1 x Acceleration Sensor PCE-PVS 30
1 x MIL-C 5015 plug to 5 m cable
1 x instruction manual
