Quality Control Micrometer
4150000
| Κωδικός | Range | Feet | Τιμή | Στοκ | ||
|---|---|---|---|---|---|---|
| MA-4150000 | 0-25 mm | - | €1.155,00 | 5-8 εργάσιμες | ||
| MA-4150001 | 25-50 mm | - | €1.403,00 | 5-8 εργάσιμες | ||
| MA-4150200 | 0-25 mm | Ceramic tipped | €1.298,00 | 5-8 εργάσιμες | ||
| MA-4150201 | 25-50 mm | Ceramic tipped | €1.551,00 | 5-8 εργάσιμες | ||
Τιμές χωρίς ΦΠΑ 24%
Technical Specifications
-
Measuring range: 0–25 mm, 25–50 mm or 0–1", 1–2"
-
Measuring surface: carbide or ceramic
-
Reading: 0.01 mm / 0.0001"
-
Error limit: 2 μm or 0.00008"
-
Parallelism deviation: 1 μm
-
Flatness deviation: 0.2 μm
-
Screw pitch: 0.5 mm or 0.025"
-
Measuring force: 9 N
-
Contact surface standard: Flat
-
Dial measurement range: ±65 μm or ±0.025"
-
Dial reading: 1 μm or 0.00005"
-
Error limit Gt: 1 μm or 0.00005"
-
Includes: user manual, case
Description
Micrometer with built-in dial gauge for direct diameter inspection on cylindrical parts. Used for diameter, length measurements, and in precision production series.
