Adjustable Collar with Reversal
| Κωδικός | παίρνει κολαούζα | Κώνος | Περιλαμβάνει | Τιμή | Στοκ | ||
|---|---|---|---|---|---|---|---|
| VTA7-B16 | M2-M7 | B16 | MT1 - MT2 - FC11 | €322,00 | 1 διαθέσιμo | ||
| VTA12-B16 | M3-M12 | B16 | MT1 - MT2 - FC21 | €393,00 | 1 διαθέσιμo | ||
| VTA20-M20 | M8 (DIN 371)-M20 | B16 | MT1 - MT2 - FC31 | €598,00 | 2 διαθέσιμα | ||
* Κ.Π. : Κατόπιν Παραγγελίας
These tapping heads can create threads ranging from (M2-M7), (M3-M12), and (M8-M20), depending on the selection. They feature a torque adjustment capability (with a numerical scale) to prevent tap breakage.
They are equipped with an anti-vibration clutch, which has a unique double-spring design. This mechanism allows for automatic disengagement during clockwise movement (CW) and smooth engagement during counterclockwise movement (CCW). The counterclockwise movement retracts the tap faster than the clockwise movement, significantly increasing productivity.
The cone in the head uses round, flexible collets to adjust the size and ensure the concentric alignment of the tap. The rear square end of the tap is held by a self-centering two-jaw clamping plate, which provides the primary motion to the tap during operation.
