Ultrasonic Thickness Gauges
Παχύμετρο υπερήχων Insize ISU-200D με ψηφιακή οθόνη LCD και αισθητήρα N05 σε καλώδιο
Τεχνικά χαρακτηριστικά ISU-200D - Παχύμετρο Υπερήχων Insize
Παχύμετρο υπερήχων Insize ISU-200D με ψηφιακή οθόνη LCD και αισθητήρα N05 σε καλώδιο
Τεχνικά χαρακτηριστικά ISU-200D - Παχύμετρο Υπερήχων Insize

Availability & price

Code Range (mm) Reading (mm) Ø Probe (mm) Availability excl. VATincl. VAT Certificate Cart
ISU-200D 0.8-300 0.01 13
€751,00
€931,24
0
  • Range: 0.8-300 mm (with the standard N05 probe)
  • Reading (resolution): 0.01 mm
  • Accuracy: ±0.05 mm (H<10 mm), ±(0.05 + H×0.001) mm (H>10 mm), where H is the thickness to be measured in mm
  • Measuring modes: single point, scanning, deviation
  • 500-measurement memory
  • Zero & two-point calibration, with automatic system error correction
  • Alarm limit setting (upper/lower) for out-of-tolerance measurements
  • Measures thickness from one side of the object — suitable for pipes, tanks, etc.
  • Applicable materials: steel, cast iron, aluminium, copper, plastics, ceramics, glass, fiberglass, etc.
  • Accepts optional probes: N02 (cast steel), N07 (thin materials), W05 (wall thickness), HT5 (high temperatures up to 310°C)
  • Minimum pipe size for measurement: Ø25 mm x 3 mm (with the N05 probe)
  • Operating temperature: -10~50°C
  • Velocity: 1-9999 m/s
  • Measurement frequency: 4 times/second
  • Output / units: mm / inch
  • USB port, LCD display with backlight, 4.00 mm calibration block
  • Power: 3 x 1.5V AAA batteries
  • Dimensions: 150 x 70 x 30 mm
  • Weight: 180 g
Datasheet Technical datasheet CE Certificate Quality document Catalog Full manufacturer catalog

Complementary products

Frequently bought together

Insize

Official distributor

Insize

INSIZE was founded in 1995 and is one of the world's leading manufacturers of measuring instruments and metrological equipment. With factories in China and other Asian countries, as well as production units in Germany and Italy for the INSIZE PLUS series, the company offers products that stand out for their accuracy, durability and reliability, while being distinguished by their excellent quality-price ratio.

This product belongs to the collection

Ultrasonic Thickness Gauges

You're viewing one product from this category. Browse the full range.

15 products
View all

Related categories

All categories →
Hardness Testers Coating Thickness Gauges18 products Eddy Current Testing1 products Metal Conductivity Meters1 products Roughness Testers16 products
Ultrasonic Thickness Gauges

From our Wiki

Ultrasonic Thickness Gauges

Ultrasonic thickness gauges are non-destructive testing (NDT) instruments that measure the thickness of materials with access from only one side. They operate by emitting high-frequency sound waves, which travel through the material, reflect off the back surface, and return to the sensor, calculating thickness based on the speed of sound propagation.

  • Applications: Ideal for measuring corrosion in piping, fuel tanks, ship hulls, and metal structures without interrupting their operation.
  • Materials: Suitable for metals, plastics, glass, ceramics, and composite materials, provided there is good sound conductivity.
  • Features: They include Echo-to-Echo functions for measurement through paint and automatic compensation for different material temperatures.
Read the guide
