Name: WNMG0804**-UG Inserts for Steels - Continuous Cutting
Brand: Yg
SKU: WNMG080404-UG-YG3125
Price: 8.68 EUR
Availability: InStock

Offers

Πλακίδι WNMG0804-UG κίτρινο με επικάλυψη, τριγωνικό σχήμα για κοπή ατσαλιών, με κεντρική οπή στήριξης

Τεχνικά χαρακτηριστικά WNMG0804**-UR - Πλακίδια WNMG0804**-UR για Ατσάλια - Βαριές Κοπές και Ξεχόντρισμα (σελ. 1)

Τεχνικά χαρακτηριστικά WNMG0804**-UR - Πλακίδια WNMG0804**-UR για Ατσάλια - Βαριές Κοπές και Ξεχόντρισμα (σελ. 2)

Τεχνικά χαρακτηριστικά WNMG0804**-UR - Πλακίδια WNMG0804**-UR για Ατσάλια - Βαριές Κοπές και Ξεχόντρισμα (σελ. 3)

Τεχνικά χαρακτηριστικά WNMG0804**-UR - Πλακίδια WNMG0804**-UR για Ατσάλια - Βαριές Κοπές και Ξεχόντρισμα (σελ. 4)

P

M

K

N

S

H

Description

Machining Materials

(P) - Steels - Alloy Steels

Chipbreaker

(UG) - Geometry for general machining of steels. It features a relatively large rake angle for smoother chip flow and a reinforced cutting edge with a flat section on the edge (T-land). Suitable for medium machining and continuous cutting. Combines toughness and high wear resistance

Grade

YG3020 – First choice for general steel machining (P15–P30). CVD TiCN–Al₂O₃ coating. Substrate specially designed for high toughness and smooth surface for increased wear resistance.

Feed

Fn = 0.20~0.40 mm/rev

Cutting Speed

(P1-5) - Vc=160~380 m/min
(P5-9) - Vc=140~320 m/min
(P10-11) - Vc=60~130 m/min

Turning inserts from YG1, a top cutting tool manufacturer from Korea. The choice of the appropriate insert depends on the chipbreaker, i.e., the geometry that helps break and remove the chip, as well as the grade, which describes the microstructure and coating of the insert and directly affects hardness and toughness. The cutting conditions (speed, feed, depth) must be carefully set to achieve maximum tool performance and life.

Technical Documents

PDF

Datasheet

PDF

Catalog

Code	Cutting Depth mm	Radius mm	Grade	Availability	Price excl. VAT incl. VAT
WNMG080404-UG-YG3125	0.5~3.0	0.4	YG3125	10 available Αποθήκη Yg: 100 available. Estimated delivery 5–8 business days. Details Αποθήκη Yg: 100 available. Estimated delivery 5–8 business days.	€7,00 €8,68
WNMG080408-UG-YG3125	1.0~3.0	0.8	YG3125	25 available Αποθήκη Yg: 100 available. Estimated delivery 5–8 business days. Details Αποθήκη Yg: 100 available. Estimated delivery 5–8 business days.	€7,00 €8,68
WNMG080408-UG-YG3020	1.0~3.0	0.8	YG3020	1 available	€7,00 €8,68 €6,00 €7,44
WNMG080412-UG-YG3125	1.5~3.0	1.2	YG3125	5-8 business days Αποθήκη Yg: 100 available. Estimated delivery 5–8 business days. Details Αποθήκη Yg: 100 available. Estimated delivery 5–8 business days.	€7,00 €8,68
WNMG080416-UG-YG3125	2.0~4.0	1.6	YG3125	5-8 business days Αποθήκη Yg: 100 available. Estimated delivery 5–8 business days. Details Αποθήκη Yg: 100 available. Estimated delivery 5–8 business days.	€7,00 €8,68
