Dial & Centering Indicators
Insize 7107-1 system for simultaneous measurement with dial indicators, unit with cables and laptop with software
Technical specifications 7107-1 - System for Simultaneous Measurement with Dial Indicators
Insize 7107-1 system for simultaneous measurement with 4 digital indicators, interface unit and laptop
Insize 7107-1 system for simultaneous dial indicator measurement, metal box with 4 DB9 IN sockets
Insize 7107-1 unit with RS485/RS232 ports, ON/OFF switch, DC 9–24V input and POWER LED in a metal housing
Insize 7107-1 unit for simultaneous dial indicator measurement, with RS485/RS232 ports and ON/OFF switch
Insize 7107-1 system for simultaneous dial indicator measurement, metal box with 8 DB9 input ports
Insize 7107-1 system for simultaneous measurement with 2 dial indicators on a transparent stand, with cables and interface unit
Insize 7107-1 system for simultaneous measurement with dial indicators, unit with cables and laptop with software
Technical specifications 7107-1 - System for Simultaneous Measurement with Dial Indicators
Insize 7107-1 system for simultaneous measurement with 4 digital indicators, interface unit and laptop
Insize 7107-1 system for simultaneous dial indicator measurement, metal box with 4 DB9 IN sockets
Insize 7107-1 unit with RS485/RS232 ports, ON/OFF switch, DC 9–24V input and POWER LED in a metal housing
Insize 7107-1 unit for simultaneous dial indicator measurement, with RS485/RS232 ports and ON/OFF switch
Insize 7107-1 system for simultaneous dial indicator measurement, metal box with 8 DB9 input ports
Insize 7107-1 system for simultaneous measurement with 2 dial indicators on a transparent stand, with cables and interface unit

Availability & price

4 codes

Code Type Availability excl. VATincl. VAT Certificate Cart
7107-1 Box for 4 dial indicators
€202,00
€250,48
0
7107-2 Box for 8 dial indicators
€336,00
€416,64
0
7309-C01M Cable
€85,00
€105,40
0
7107-3 connection for 4 Boxes
€189,00
€234,36
0

= Express from Europe: at our premises in 1-2 working days, from €35 + VAT Express from Europe, from €35 + VAT

Express from Europe

At our premises in 1-2 working days if you place the order by 13:00
Cost depending on weight from €35 + VAT

If it takes more than 2 working days, we refund the cost.

Contact us

info@organametrisis.gr 210 2231624

Mon–Fri 08:30–18:00

Description

  • Interface boxes are supplied with software: set tolerance of each channel and show judgment (red when out of tolerance, green when within tolerance), set zero, collect data manually or automatically (time is adjustable), output data to Excel, print report
  • Connection box (code: 7107-3) is needed to connect interface boxes when two or more interface boxes are used, maximum 4 interface boxes can be connected
  • Cable length 2 m
  • Long press transmission button or foot switch to zero the digital indicators
  • Connects to 2112, 2114, 2115, 2116, 2501, 2103 and 2104 series digital indicators (cable 7309-C01M is needed)
  • Connects to 7107-11, 7107-12, 7107-11V or 7107-12V linear gauges

Technical Documents 3

Datasheet Technical datasheet Manual User manual Catalog Full manufacturer catalog

Complementary products

Frequently bought together

Insize

Official distributor

Insize

INSIZE was founded in 1995 and is one of the world's leading manufacturers of measuring instruments and metrological equipment. With factories in China and other Asian countries, as well as production units in Germany and Italy for the INSIZE PLUS series, the company offers products that stand out for their accuracy, durability and reliability, while being distinguished by their excellent quality-price ratio.

This product belongs to the collection

Dial & Centering Indicators

You're viewing one product from this category. Browse the full range.

181 products
View all

Related categories

All categories →
Calipers117 products Micrometers116 products Bore Micrometers22 products Indicator Stands56 products Cylinder Bore Gauges25 products
Dial Indicators

From our Wiki

Dial Indicators

The dial indicators (or comparative gauges) are high-precision measuring instruments used to check the deviations of a surface from a reference point. They are essential for machine tool setup and component quality control, as they can detect differences on the order of 0,01 mm or even 0,001 mm.

  • Types:Face (Plunger Type): They have a spindle that moves linearly up and down. Ideal for measuring flatness and perpendicularity.Test indicators (Lever Type): They have a rotating stylus (lever). They are extremely versatile for measurements in hard-to-reach areas or for checking radial deviation (run-out) on lathes.
  • Applications: * Alignment of parts in the lathe chuck.Checking parallelism on milling machine tables.Measuring wear on brake discs or engine shafts.
  • Use with Magnetic Base: For the indicator to operate, it must be mounted on a stable magnetic base with articulated arms, so that it remains stationary during the measurement.
Read the guide
