| Air pressure | |
| Accuracy | ± 0.3% of reading at 25°C / 77°F |
| Repeatability | ± 0.2% (± 0.5% of reading) |
| Linearity / hysteresis | ± 0.29% of reading |
| Pressure range | 5000 Pa |
| Maximum pressure | 10 psi |
| Response time | Usually 0.5 seconds |
| Measuring range |
0.7252 psi 50.00 mbar 20.07 inH2O 509.8 mmH2O 5000 Pa |
| Reading |
0.0001 psi 0.01 mbar 0.01 inH2O 0.1 mmH2O 1 Pa |
| Selectable units | Mbar, psi, inH2O, mmH2O or Pa |
| Air velocity | |
| Measuring range |
1 ... 80 m / s 200 ... 15733 ft / min 3.6 ... 288 km / h 2.24 ... 178.66 MPH 2 ... 154.6 knots |
| Reading |
0.01 m / s 1 ft / min 0.1 km / h 0.01 MPH 0.1 knots |
| Accuracy |
In m/s: ± 2.5% of the measured value In ft/min, Km/h, MPH and Knot: Depending on air velocity and duct size |
| Flow rate | |
| Measuring range |
0 ... 99999 m³ / min 0 ... 99999 ft³ / min |
| Reading |
0.001 ... 100 m³ / min 0.0001 ... 100 ft³ / min |
| Temperature | |
| Measuring range | 0 ... 50°C / 32 ... 122°F |
| Reading | 0.1°C / 0.18°F |
| Accuracy | ± 1°C / ± 1.8°F |
| General description | |
| Pitot tube diameter | 8 mm / 0.3 in |
| Length of measuring tubes | Every 85 cm / 33.46 in |
| Total length of the tube | 335 mm / 13.18 in |
| Low battery indication | Yes |
| Power supply | 9V battery |
| Operating conditions | 0 ... 50°C / 32 ... 122°F / <90% RH non-condensing |
| Storage conditions | -10 ... 60°C / 14 ... 140°F / <90% RH non-condensing |
| Internal memory | 99 measured values per parameter |
| Output | USB |
| Display | LCD |
| Housing | ABS plastic |
| Dimensions |
Device: 206 x 95 x 45 mm / 8.11 x 3.7 x 1.7 in Pitot tube: 335 mm / 13.18 in - Ø 8 mm / 0.31 in |
| Weight (including pitot tube, battery, and flexible measuring tubes) | 600 g / 1.3 lbs |
PCE-HVAC 2 Anemometer - Thermometer with pitot tube
Measures air speeds up to 80 m/s (178.66 mph) / Zero, minimum, maximum, average, recording, and hold functions / Stores up to 99 measurement values per parameter in memory
The PCE-HVAC 2 is a high-speed multifunction anemometer with a pitot tube. This portable instrument can be used to determine air velocity, air pressure, air flow, differential pressure, and ambient temperature. The pitot tube allows access through microscopic openings to take measurements in small pipe systems and other confined spaces.
- Measures air speeds up to 80 meters per second (m/s)
- Indications zero, minimum, maximum, average, record, and hold
- Stores up to 99 measurement values per parameter in memory
Stored measurement values can be recalled or read later on the device itself or on a computer. Transfer to a computer works easily via USB interface. Real-time measurement can also be performed through this connection. When connected via USB, the measured values are displayed on the computer screen using downloadable computer-compatible software. Besides ergonomic design, the anemometer features a backlit display that allows use in low-light conditions. The PCE-HVAC 2 has a thread at the bottom so the device can be mounted on a tripod. The flexible measuring tubes are inserted at the top of the device allowing connection to the pitot tube.
- Measures air velocity, air pressure, air flow
- Displays ambient temperature
- Zero adjustment function
- MIN, MAX, AVR, REC, and HOLD functions
- LCD backlight
- Dual display on the LCD screen
- Suitable for high flow rates
- Internal memory for 99 measurement values per parameter
- USB cable included
- Computer-compatible software with download capability
- Real-time measurement
- Pitot tube measurement
- Differential pressure and standard measurement
- 2 flexible connection hoses (85 cm each / 33.46 inches)
- Adjustable measurement units
- ISO calibration available
Package contents
1 x Pitot tube (angled)
1 x USB cable
1 x Carrying case
1 x Software
2 x Flexible connection hose (85 cm each)
1 x 9 V battery
1 x Instruction manual
| Code | Width | Reading | Accuracy | Availability | Price excl. VAT | Price incl. VAT | Certificate | Cart |
|---|---|---|---|---|---|---|---|---|
| PCE-HVAC 2 | 1-80 m/s | 0.01 m/s | 2.5 |
€390,00
|
€483,60
|
