Moisture Scales

Availability & price

Code Range (g) Graduation (g) Moisture Resolution (%) Availability excl. VATincl. VAT Certificate Cart
PCE-MA 200 200 0.001 0.01 1 in stock
€840,00
€1.041,60
0

Description

  • Weighing range 200 g
  • Readability 0.001 g
  • Moisture accuracy 0.01 %
  • Halogen heating up to 199 °C
  • 15 drying programmes
  • RS-232 interface

The PCE-MA 200 is a halogen moisture analyser. It weighs a sample, dries it in a heated chamber and calculates the moisture content from the loss in weight.

Halogen lamps heat the chamber from 40 to 199 °C. The weighing range is 200 g with 0.001 g readability, and moisture is measured from 0 to 100 % with 0.01 % resolution. Results are shown on the large backlit LCD. Up to 15 drying programs can be stored, and drying temperature and time are adjustable. An RS-232 interface is fitted. Typical uses are quality control of wood products, granules, pellets, feed, food and pastes. A 100 g weight is included for calibration at any time.

Highlights

  • Weighing range 200 g, readability 1 mg / 0.001 g
  • Halogen heating chamber, 40 ... 199 °C
  • Accuracy to 0.01 %
  • Memory for up to 15 drying programs
  • Adjustable drying temperature and time
  • RS-232 interface
  • Large backlit LCD, nine membrane keys
  • Calibration with the included 100 g weight

Specifications

Absolute moisture
Measuring range0 ... 100 %
Resolution0,01 %
Weighing range
Measurement range up to [Max]200 g
Resolution [d]0,001 g
Accuracy0.003 g
General technical data
Display typeLCD with backlight
Digit size [WxH]H: 17 mm
Storage capacity15 Programs
InterfaceRS232
Heating elementHalogen light
Heating temperature40 ... 199 °C
Repeatability0,003 g
DimensionsHalogen lamp: Ø 90 mm
Drying time1 ... 99 min.
Settling time4 s
Linearity0.003 g
Readability0,001 g
Menu languageEnglish, English (GB)
Protection class (device)IP20
Power supply220 V / 50 Hz
Connector typeCold-device plug
Operating conditions5 ... 35 °C , 0 ... 75 % RH
Storage conditions0 ... 40 °C , 0 ... 75 % RH
Dimensions ( L x W x H )200 x 180 x 380 mm
Weight4400 g

Package Contents

  • Delivery contents
  • 1×PCE-MA 200 Relative Humidity Meter
  • 1×wind protection shield
  • 1×sample pans
  • 1×power supply cord
  • 1×sample cup holder / handle
  • 1×100 g weight in plastic box
  • 1×user manual
