Dynamometer cells with 0-2V output up to 300 tons

Name: Dynamometer cells with 0-2V output up to 300 tons
Brand: Eilon
SKU: Ron4000VS005
Price: 5682.92 EUR
Availability: InStock

IP65

PDFDatasheet PDFManual PDFCatalog

Same-day dispatchfor orders placed by 15:00

Free shippingon orders over €80 (incl. VAT)

ISO 17025 calibrationupon request

IPXY

X = Protection against solid objects & access to hazardous parts
Y = Protection against water ingress

Value	1st Digit – Solids / Access	2nd Digit – Water
0	No protection	No protection
1	Protection against solids ≥50 mm (test probe Ø50 mm)	Vertical falling drops
2	Protection against solids ≥12.5 mm (test probe Ø12.5 mm)	Drops with tilt up to 15°
3	Protection against solids ≥2.5 mm (test probe Ø2.5 mm)	Spraying up to 60°
4	Protection against solids ≥1 mm (test probe Ø1 mm)	Splashing from all directions
5	Protection against dust (limited ingress without harmful effects)	Water jets (nozzle 6.3 mm)
6	Complete dust-tightness (dust-tight)	Powerful water jets (nozzle 12.5 mm)
7	—	Temporary immersion (usually 1 m / 30 min)
8	—	Continuous immersion (depth & time specified by manufacturer)
9 / 9K	—	High-pressure & high-temperature water jets

Availability & price

20 codes

Code	Capacity	Resolution	Availability	excl. VAT	incl. VAT	Certificate
Ron4000VS005	500 kg	200 g	On Order	€4.583,00	€5.682,92	Calibration attached Press + to add to cart
Ron4000VS01	1 t	500 g	On Order	€4.602,00	€5.706,48	Calibration attached Press + to add to cart
Ron4000VS02	2 t	1 kg	On Order	€4.621,00	€5.730,04	Calibration attached Press + to add to cart
Ron4000VS03	3 t	1 kg	On Order	€4.635,00	€5.747,40	Calibration attached Press + to add to cart
Ron4000VS05	5 t	2 kg	On Order	€4.654,00	€5.770,96	Calibration attached Press + to add to cart
Ron4000VS10	10 t	5 kg	On Order	€4.771,00	€5.916,04	Calibration attached Press + to add to cart
Ron4000VS12	12.5 t	5 kg	On Order	€4.783,00	€5.930,92	Calibration attached Press + to add to cart
Ron4000VS15	15 t	5 kg	On Order	€4.943,00	€6.129,32	Calibration attached Press + to add to cart
Ron4000VS20	20 t	10 kg	On Order	€4.980,00	€6.175,20	Calibration attached Press + to add to cart
Ron4000VS25	25 t	10 kg	On Order	€5.022,00	€6.227,28	Calibration attached Press + to add to cart
Ron4000VS30	30 t	10 kg	On Order	€5.075,00	€6.293,00	Calibration attached Press + to add to cart
Ron4000VS40	40 t	20 kg	On Order	€5.699,00	€7.066,76	Calibration attached Press + to add to cart
Ron4000VS55	55 t	20 kg	On Order	€6.212,00	€7.702,88	Calibration attached Press + to add to cart
Ron4000VS85	85 t	50 kg	On Order	€8.835,00	€10.955,40	Calibration attached Press + to add to cart
Ron4000VS100	100 t	50 kg	On Order	€15.140,00	€18.773,60	Calibration attached Press + to add to cart
Ron4000VS125	125 t	50 kg	On Order	€15.300,00	€18.972,00	Calibration attached Press + to add to cart
Ron4000VS150	150 t	50 kg	On Order	€20.064,00	€24.879,36	Calibration attached Press + to add to cart
Ron4000VS200	200 t	100 kg	On Order	€27.869,00	€34.557,56	Calibration attached Press + to add to cart
Ron4000VS250	250 t	100 kg	On Order	€28.923,00	€35.864,52	Calibration attached Press + to add to cart
Ron4000VS300	300 t	100 kg	On Order	€40.990,00	€50.827,60	Calibration attached Press + to add to cart

The Ron 4000 is an analog load cell with an integrated amplifier, does not include a display unit, and is designed for connection to PLCs or similar devices capable of interpreting an analog signal. 5 years warranty Portability: Lightweight and small. Available with a Pelican™ carrying case. High linearity: ± 0.1% of full scale. Materials: Exclusive use of high-quality aerospace steel for load cell bodies. Design: Heavy-duty type with integrated amplifier for direct and easy connection to control systems. Meets Standards: All Eilon Engineering load cells have fatigue ratings according to ASME BTH-1-2017, ASME B30.26, and IEC 61508.
