Needle tip Ø1.5mm Overall length 16mm Head Ø4.7mm Thread M2.5-6g Manufactured by Kafer, Germany For measuring in grooves and hard-to-reach points.

Needle tip Ø1.5mm Available lengths 20-45mm Head Ø4.7mm Thread M2.5-6g Manufactured by Kafer, Germany For deep holes and recesses beyond the reac...

Precision disc tip Ø7.8 and Ø10mm Flatness tolerance 0.005mm Parallelism tolerance 0.02mm Thread M2.5-6g Manufactured by Kafer, Germany For deman...

Flat disc tip Ø15 and Ø20mm Thickness 1.5-2mm N4 surface finish Thread M2.5-6g Manufactured by Kafer, Germany For large flat surfaces.

Flat disc tip Ø7.8 and Ø10mm Thickness 1-2mm N4 surface finish Thread M2.5-6g Manufactured by Kafer, Germany For thin, flat surfaces.

Flat head Ø10mm Radius R15 Height 2mm Thread M2.5-6g Manufactured by Kafer, Germany For measuring on soft or uneven surfaces.

Flat tip Ø7.8 and Ø10mm Thickness 2mm Stem Ø4.5mm Thread M2.5-6g Manufactured by Kafer, Germany For measuring on soft materials and rubber.

Domed tip Ø10mm Radius R6 Height 4.5mm Thread M2.5-6g Manufactured by Kafer, Germany For gentle contact on delicate surfaces.

Cylindrical tip with flat face Ø5mm Available lengths 3-20mm Thread M2.5-6g Manufactured by Kafer, Germany For flat surfaces needing a stable seat.

Cylindrical tip with flat face Ø7.8mm Various lengths Thread M2.5-6g Manufactured by Kafer, Germany A larger bearing surface than the Ø5mm version.

Cylindrical tip with spherical R4.5 face Ø5mm Available lengths 3-20mm Thread M2.5-6g Manufactured by Kafer, Germany Combines a stable seat with ...

Conical tip 45° Ø4.5mm Length 10mm Thread M2.5-6g Manufactured by Kafer, Germany For centring in holes and conical seats.

Conical tip 60° Ø4.5mm Length 10mm Thread M2.5-6g Manufactured by Kafer, Germany Wider angle for shallower conical seats.

Sharp conical tip 20° 0.2mm point Ø5mm, length 16mm SW5 wrench flats Thread M2.5-6g Manufactured by Kafer, Germany For scribing and point contact.

Fine tapered tip with R0.5 radius Ø3.5mm Overall length 16mm Thread M2.5-6g Manufactured by Kafer, Germany For point contact on small surfaces.

Fine tapered tip 15° with R0.5 radius Ø3.5mm Available lengths 5-40mm Thread M2.5-6g Manufactured by Kafer, Germany For point measurement at depth.

Knife-edge tip, 0.5mm edge Length 9mm SW5 wrench flats Thread M2.5-6g Manufactured by Kafer, Germany For measuring in grooves and on edges.

Rotating disc Ø7.5mm Flatness tolerance 0.005mm SW5 wrench flats Thread M2.5-6g Manufactured by Kafer, Germany For checking moving or rotating su...

Rotating roller Ø10mm Lengths 15 and 25mm SW5 wrench flats Thread M2.5-6g Manufactured by Kafer, Germany For continuous measurement on moving sur...

Rotating roller Ø8.4mm Width 8.7mm SW5 wrench flats Thread M2.5-6g Manufactured by Kafer, Germany For measuring on moving surfaces without wear.
