Display for Anemometer
PCE-WSAC 50
| Κωδικός | Connectivity | Voltage | Sensor Signal | Τιμή | Στοκ | ||
|---|---|---|---|---|---|---|---|
| PCE-WSAC 50-110 | - | 230 V | 4-20mA | €492,00 | 1 διαθέσιμo | ||
| PCE-WSAC 50-120 | - | 230 V | 0-10 V | €492,00 | 5-8 εργάσιμες | ||
| PCE-WSAC 50-210 | - | 115 V | 4-20mA | €492,00 | 5-8 εργάσιμες | ||
| PCE-WSAC 50-220 | - | 115 V | 0-10 V | €492,00 | 5-8 εργάσιμες | ||
| PCE-WSAC 50-310 | - | 24 V | 4-20mA | €492,00 | 5-8 εργάσιμες | ||
| PCE-WSAC 50-320 | - | 24 V | 0-10 V | €492,00 | 5-8 εργάσιμες | ||
| PCE-WSAC 50-111 | RS485 | 230 V | 4-20mA | €570,00 | 5-8 εργάσιμες | ||
| PCE-WSAC 50-121 | RS485 | 230 V | 0-10 V | €570,00 | 5-8 εργάσιμες | ||
| PCE-WSAC 50-211 | RS485 | 115 V | 4-20mA | €570,00 | 5-8 εργάσιμες | ||
| PCE-WSAC 50-221 | RS485 | 115 V | 0-10 V | €570,00 | 5-8 εργάσιμες | ||
| PCE-WSAC 50-311 | RS485 | 24 V | 4-20mA | €570,00 | 5-8 εργάσιμες | ||
| PCE-WSAC 50-321 | RS485 | 24 V | 0-10 V | €570,00 | 5-8 εργάσιμες | ||
| Power supply | 230V AC | |
| Supply voltage for sensors (output) |
12V DC 24V DC |
|
| Measuring range | 0 ... 50 m/s | |
| Measurement accuracy | ± 3% of the measuring range | |
| Signal input |
4 ... 20 mA |
|
| Alarm relay |
|
|
| Output | RS485 | |
| Operating temperature | -20 ... 60°C / -4 ... 140°F | |
| Protection class | IP66 (Waterproof) | |
| Dimensions | 197.5 x 90 x 45 mm / 7.7 x 3.5 x 1.7 in |
***Sensors sold separately***
Anemometer / Wind warning device PCE-WSAC 50-111
with pre-alarm and alarm / Connection via RS485 / wind speed display / easy operation / display of the average speed of the last 2 and 5 minutes
The wind warning device can be used in various fields of application as it is characterized by high reliability and accuracy. It can be used on the one hand to monitor the current wind speed, on the other hand it is possible to calculate the average value of the speed of the last two or five minutes. If the measurements are higher than the preset values, a pre-alarm is first activated and then the normal alarm with acoustic and visual signals. When the pre-alarm is activated, a yellow LED flashes on the front of the device and an acoustic signal is emitted periodically. When the normal alarm is activated, the red LED flashes and the acoustic signal is emitted continuously by the device.
In general, the wind warning device is used wherever wind monitoring is required. This often happens in factories, mines and wind turbines. The wind measuring device is characterized by high reliability and accuracy.
***Sensors sold separately***
- Wind warning device with adjustable alarms
- 2 types of alarms
- Power supply: 230 V AC
- Input signal: 4 ... 20 mA
- Connectivity: RS485
- Installed 2 alarm relays
- Built-in buzzer for acoustic notification
- Sensor power supply via evaluation device
Package contents
1 x Anemometer PCE-WSAC 50-111
1 x User manual
1 x Sensor socket
