ISU-100D - Ultrasonic thickness gauge with range 0.8-300 mm
| Κωδικός | Range | Reading | Ø Probe | Τιμή | Στοκ | ||
|---|---|---|---|---|---|---|---|
| ISU-100D | 0.8-300 mm | 0.01 mm | Ø 10.8 mm | €478,00 | 15-18 εργάσιμες | ||
Τιμές χωρίς ΦΠΑ 24%
- Range: 0.8-300mm
- Reading: 0.01mm (range＜100mm), 0.1mm (range ≥ 100mm)
- Repeatability: 0.03mm (range＜100mm), 0.1mm (range ≥ 100mm)
- Accuracy: ±0.04 mm (range＜10 mm), ±(0.04+H/1000) mm (range10-100 mm), ±H/333 mm (range ≥ 100 mm), H: the thickness to be measured in mm
- It measures the thickness from one side of the object, suitable for pipe, tank, etc.
- Applicable material: metal, plastic, glass, nylon, resin, ceramic, rubber, ice
- Minimum pipe size to measure: Ø20mm x 1.2mm (diameter x wall thickness)
- Operating temperature: <60ºC
- Speed: 1000-9999 m/s
- Power supply: 2 x AAA batteries
- Dimensions: 114 x 64 x 28 mm
- Weight: 200g
