Water Quality Meter pH, Conductivity, TDS, Salinity, Oxygen, Temperature
RS232
- Real-time data logger
- SD card 1 ... 16 GB
- Data saved as Excel files
- RS-232 output to PC
- pH and conductivity electrodes included
Same-day dispatchfor orders placed by 15:00
Free shippingon orders over €80 (incl. VAT)
Availability & price
| Code | Availability | excl. VAT | incl. VAT | Cart |
|---|---|---|---|---|
| PCE-PHD 1 |
€530,00
|
€657,20
|
- Real-time data logger
- SD card 1 ... 16 GB
- Data saved as Excel files
- RS-232 output to PC
- pH and conductivity electrodes included
The PCE-PHD 1 is a portable water quality data logger. It measures pH, redox, conductivity, salt content, TDS, oxygen and temperature, in the laboratory and on site. Three-point calibration and automatic temperature compensation hold accuracy when the water temperature varies. A pH electrode and a conductivity electrode are included; redox and oxygen electrodes are sold separately.
Readings are logged in real time to the SD card (1 ... 16 GB) as Excel files, so no extra software is needed to evaluate the data. An RS-232 port sends the readings straight to a PC. A mains adapter and a software kit with RS-232 cable are optional.
Highlights
- Measures pH, redox, conductivity, salt, TDS, oxygen, temperature
- Real-time logging to SD card (1 ... 16 GB)
- Data stored directly as Excel files
- RS-232 interface for online data transfer
- Automatic calibration with 3 calibration points
- Manual or automatic temperature compensation
- Adjustable measuring rate, BNC connector
- Large LC display with low battery indicator
- Robust housing for lab and field use
| Conductivity | |
|---|---|
| Measuring range | 0 ... 200 µS/cm |
| Resolution | 0,1 µS/cm |
| Accuracy | ±(2% FS +1 digit) |
| Measuring range | 0,2 ... 2 mS/cm |
| Resolution | 0,001 mS/cm |
| Accuracy | ±(2% FS +1 digit) |
| Measuring range | 2 ... 20 mS/cm |
| Resolution | 0,01 mS/cm |
| Accuracy | ±(2% FS +1 digit) |
| Measuring range | 20 ... 200 mS/cm |
| Resolution | 0,1 mS/cm |
| Accuracy | ±(2% FS +1 digit) |
| pH | |
| Measuring range | 0 ... 14 pH |
| Resolution | 0,01 pH |
| Accuracy | ±0.02 pH +2 digits |
| Redox | |
| Measuring range | -1999 ... +1999 mV |
| Resolution | 1 mV |
| Accuracy | ±0.5% +2 Digits |
| Salinity | |
| Measuring range | 0 ... 12 % |
| Resolution | 0,01 % |
| Accuracy | ±0.5 % FS |
| Oxygen | |
| Measuring range | 0 ... 20 mg/l |
| Resolution | 0,1 mg/l |
| Accuracy | ±0.4% mg/l |
| Measuring range | 0 ... 100 % |
| Resolution | 0,1 % |
| Accuracy | ±0.7% |
| TDS | |
| Measuring range | 0 ... 132 ppm |
| Resolution | 0,1 ppm |
| Accuracy | ±2% FS +1 digit |
| Measuring range | 132 ... 1320 ppm |
| Resolution | 1 ppm |
| Accuracy | ±2% FS +1 digit |
| Measuring range | 1320 ... 13200 ppm |
| Resolution | 10 ppm |
| Accuracy | ±2% FS +1 digit |
| Measuring range | 12200 ... 132000 ppm |
| Resolution | 100 ppm |
| Accuracy | ±2% FS +1 digit |
| Temperature | |
| Measuring range | 0 ... 60 °C |
| Resolution | 0,1 °C |
| Accuracy | ±0.8 °C |
| Electrode | |
| Designation | CPC-EPS-1 |
| Measuring range | 0 ... 14 pH |
| Temperature range | 0 ... 60 °C |
| Shank material | Glass |
| Cable length | 1 m |
| Designation | CDPB-03 |
| Measuring range | 0 µS/cm ... 200 mS/cm |
| Temperature range | 0 ... 60 °C |
| Shank length | 120 mm |
| Shank diameter | 22 mm |
| Cable length | 1 m |
| Connection | BNC |
| General technical data | |
| Temperature compensation | automatic, 0 to 60°C / 32 to 140°F |
| Display type | LCD |
| Display size | 2,54 in |
| Storage medium | SD card |
| Storage capacity | 16 GB |
| Memory capacity (additional information) | SD card from 1 GB to 16 GB possible |
| Storage interval from | 1 s |
| Storage interval to | 9 h |
| Interface | RS232 |
| Number of calibration points | 3 |
| Menu language | English, English (GB) |
| Protection class (device) | IP20 |
| (Rechargeable) battery | 6 x 1,5 V AA battery , Alkali-manganese |
| Capacity | 3000 mAh |
| Operating conditions | 0 ... 50 °C , 0 ... 85 % RH |
| Storage conditions | 0 ... 50 °C , 0 ... 85 % RH |
| Dimensions ( L x W x H ) | 177 x 68 x 45 mm |
| Weight | 490 g |
- 1×PCE-PHD 1 Data Logger / Data Logging Instrument
- 1×pH electrode
- 1×conductivity electrode
- 1×SD memory card
- 6×1.5 V AA batteries
- 1×user manual
