Force Gauges - Newtonmeters
Insize ISF-DF digital push-pull force gauge with LCD display, cable and sensor, with push/pull attachments
Insize ISF-DF digital push-pull force gauge with LCD display and cabled force sensor
Technical specifications ISF-DF - Digital force gauge (Newtonmeter) - Push-Pull 1kN...200kN Type B (p. 1)
Technical specifications ISF-DF - Digital force gauge (Newtonmeter) - Push-Pull 1kN...200kN Type B (p. 2)
Insize ISF-DF digital push-pull force gauge, black, with large LCD display and control buttons
Insize ISF-DF push-pull force gauge under test, digital display reading 8.04 N and measuring frame with strap
Technical specifications ISF-DF - Digital Force Gauge (Newtonmeter) - Push-Pull 1kN...200kN Type B (p. 3)
Technical specifications ISF-DF - Digital Force Gauge (Newtonmeter) - Push-Pull 1kN...200kN Type B (p. 4)
Technical specifications ISF-DF - Digital Force Gauge (Newtonmeter) - Push-Pull 1kN...200kN Type B (p. 5)
Technical specifications ISF-DF - Digital force gauge (Newtonmeter) - Push-Pull 1kN...200kN Type B (p. 6)
Insize ISF-DF digital push-pull force gauge with LCD display, cable and sensor, with push/pull attachments
Insize ISF-DF digital push-pull force gauge with LCD display and cabled force sensor
Technical specifications ISF-DF - Digital force gauge (Newtonmeter) - Push-Pull 1kN...200kN Type B (p. 1)
Technical specifications ISF-DF - Digital force gauge (Newtonmeter) - Push-Pull 1kN...200kN Type B (p. 2)
Insize ISF-DF digital push-pull force gauge, black, with large LCD display and control buttons
Insize ISF-DF push-pull force gauge under test, digital display reading 8.04 N and measuring frame with strap
Technical specifications ISF-DF - Digital Force Gauge (Newtonmeter) - Push-Pull 1kN...200kN Type B (p. 3)
Technical specifications ISF-DF - Digital Force Gauge (Newtonmeter) - Push-Pull 1kN...200kN Type B (p. 4)
Technical specifications ISF-DF - Digital Force Gauge (Newtonmeter) - Push-Pull 1kN...200kN Type B (p. 5)
Technical specifications ISF-DF - Digital force gauge (Newtonmeter) - Push-Pull 1kN...200kN Type B (p. 6)

Availability & price

5 codes

Code Range (kN)Range (kg) Resolution (N) Type Availability excl. VATincl. VAT Certificate Cart
ISF-DF1KB 1 100 0.1 B push/pull
€1.080,00
€1.339,20
0
ISF-DF2KA 2 200 0.5 B push/pull
€1.234,00
€1.530,16
0
ISF-DF5KA 5 500 0.5 B push/pull
€1.441,00
€1.786,84
0
ISF-DF10KA 10 1000 1 B push/pull
€1.560,00
€1.934,40
0
ISF-DF20KA 20 2000 5 B push/pull
€1.811,00
€2.245,64
0
  • Internal sensor
  • Reading: 0.0005N
  • Accuracy: ±0.3% (of load capacity)
  • Push-pull test
  • Functions: Peak (max.), tracking mode
  • Units: mN, N, gf, kgf, ozf, lbf
  • Memory: 1000 positions
  • Automatic power off
  • Power supply: built-in rechargeable battery
  • LCD backlit display, with 180º viewing angle rotation capability
  • Over-limit alarm
  • Software CD
  • Data output in EXCEL format
Datasheet Technical datasheet CE Certificate Quality document Catalog Full manufacturer catalog

Complementary products

Frequently bought together

Insize

Official distributor

Insize

INSIZE was founded in 1995 and is one of the world's leading manufacturers of measuring instruments and metrological equipment. With factories in China and other Asian countries, as well as production units in Germany and Italy for the INSIZE PLUS series, the company offers products that stand out for their accuracy, durability and reliability, while being distinguished by their excellent quality-price ratio.

This product belongs to the collection

Force Gauges - Newtonmeters

You're viewing one product from this category. Browse the full range.

59 products
View all

Related categories

All categories →
Precision Scales35 products Standard Weights17 products Platform Scales12 products Crane Scales31 products Moisture Analyzers13 products
Dynamometers Newtonmeters

From our Wiki

Dynamometers Newtonmeters

The dynamometers are measuring instruments used to determine the tensile or compressive force applied to a body. Their operation is usually based on the deformation of a spring or the use of electronic load cells (load cells), converting mechanical stress into a measurable unit of force, the Newton (N).

  • Types: They are classified into analog (spring) for simple applications and digital for high-accuracy measurements with data logging capability.
  • Applications: Essential for material tensile tests, spring quality control, door closing force measurement, and laboratory physics experiments.
  • Features: They offer Peak Hold function to retain the maximum value and the ability to switch units between Newton, kilograms (kg) and pounds (lb).
Read the guide
