SET Divider + Center Punch + Discs
Availability & price
2 codes
| Code | For chuck | Center height - Morse | Availability | excl. VAT | incl. VAT | Cart |
|---|---|---|---|---|---|---|
| BS-0 | 130 | 85 mm / MT2 | 2 in stock |
€534,00
|
€662,16
|
|
| BS-1 | 160 | 100 mm / MT3 | 2 in stock |
€688,00
|
€853,12
|
The divider can divide at any angle using direct, indirect, or differential methods. The transmission ratio between the screw and the gear is 40:1. Indirect division of all numbers from 2 to 50 and many numbers up to 380 is possible.
The hardened and precision-machined spindle is rigidly held in tapered roller bearings. The screw is also hardened and precision-machined. The rotating head can be locked at any angle from 10° below the horizontal axis to 90° vertical, ensuring smooth rotation thanks to the precise fit in the base.
All models feature a threaded spindle end and a dividing plate with 24 holes, with easy conversion for quick direct division into numbers 2, 3, 4, 6, 8, 12, and 24.
Accurate precision, minimal backlash, excellent appearance, and robust construction ensure smooth rotation.
Includes
