| Measuring range | 200 ... 900 HL |
| Measurement accuracy | ± 0.8% at HLD=900 |
| Materials | 9 common material presets |
| Hardness units |
Leeb: HL Rockwell C: HRC Rockwell B: HRB Brinell: HB Vickers: HV Shore: HSD |
| Display | LCD 12.5 mm / 0.5" with backlight |
| Impact detector | Type D |
| Memory | 50 data sets |
| Output | RS-232 |
| Power supply | 4 x 1.5V AAA batteries |
| Environmental conditions |
Operating temperature: -10 ... 50°C / 14 ... 122°F Storage temperature: -30 ... 60°C / -22 ... 140°F Relative humidity: < 90% |
| Dimensions | 142 x 77 x 40 mm / 5.59 x 3.03 x 1.58 in |
| Weight |
Device weight: approximately 130 g / < 1 lb Probe weight: 75 g / < 1 lb |
| Cable length | approximately 1.2 m / 3.9 ft |
PCE-900 Portable Rebound Hardness Tester / Tensile Strength Measurement / 9 Pre-Calibrated Materials / Conversion to 5 Different Hardness Scales / Type D Impact Probe
The Leeb hardness tester PCE-900 measures the hardness of nine different metals using the Leeb rebound method. This means that with the hardness detector, a impact pin bounces on a metal surface and the intensity of the rebound is used as an indicator of the material's hardness. The PCE-900 hardness tester measures the metal hardness on 5 different hardness scales (Rockwell, Vickers, Leeb, Brinell, and Shore, with Rockwell measurements distinguished in B and C). The impact probe is type D. This probe can be used for many measurements. Thanks to the provided software, the measured values can be transmitted directly to a PC. The tester comes with an ISO calibration certificate, which certifies the accuracy of the measuring device with traceability capability. This makes the PCE-900 Leeb hardness tester an important tool in the field of material inspection and product control.
Features:
- Displays measurements in: Leeb, Rockwell C, Rockwell B, Brinell, Vickers, or Shore hardness units
- Accuracy ± 0.8% with HLDmax = 900
- Hardness Test by Rebound Method
- 9 Material Presets
- Easy to use
- ISO Calibration Certificate Included
- Output: RS-232
- Impact Sensor: Type D
The package includes:
1 x PCE-900 Portable Hardness Tester
1 x Type D Impact Probe
1 x Standard Test Block
1 x Support Ring
1 x Cleaning Brush
1 x User manual
1 x Factory Calibration Certificate
3 x AAA Batteries
1 x Carrying case
1 Year Warranty
PCE Instruments Factory
The PCE Deutschland GmbH, known as PCE Instruments, is a German company based in Meschede, which from 1999 to the present has established itself internationally as a reliable manufacturer and supplier of measuring, testing, and weighing instruments. The company offers an exceptionally wide range of instruments – from vibration, humidity, noise, and temperature meters to precision scales, analyzers, sensors, and data loggers – covering every need in industry, laboratories, and research.
PCE Instruments products are used in a wide range of sectors such as industrial production, quality control, equipment maintenance and assurance, environmental measurement, energy inspection, as well as education and scientific research. With a combination of know-how, reliability, and flexibility, the company provides complete solutions that ensure accurate results and contribute to improving measurement and testing processes in every professional sector.
Official Representation
Our company, ΤΡΙΑΝΤΑΦΥΛΛΟΥ Κ ΣΙΑ Ε.Ε. is the official representative of PCE Instruments in Greece since 2015. We have a large variety of Pce products in stock, which is continuously increasing. In addition, we can support the entire range of its catalog, which includes more than 5,000 different product codes.
In our store we provide technical support for all PCE Instrumentrs products via trained technicians, while ensuring high availability of spare parts, ensuring prompt service and reliability for our customers.
All of its products meet European specifications, following various international quality and safety standards.
