Metal Hardness Testers
PCE-900 portable Leeb rebound hardness tester with digital display and D-type impact device with cable
Leeb D-type impact device for PCE Instruments PCE-900 hardness tester, black-silver with blue cable
PCE Instruments PCE-900 portable Leeb rebound hardness tester with large LCD display and control buttons
PCE Instruments PCE-900 portable Leeb rebound hardness tester in use, probe on a metal shaft
Technician using PCE Instruments PCE-900 portable Leeb rebound hardness tester on a metal bar in a workshop
PCE Instruments PCE-900 portable Leeb rebound hardness tester in use on a metal surface, with probe cable
PCE data acquisition system for ultrasonic thickness gauge, with display unit and PC software screenshots
PCE-900 portable Leeb rebound hardness tester with LCD display, keypad and cabled impact device, with calibration certificate...
PCE-900 portable Leeb rebound hardness tester with digital display and D-type impact device with cable
Leeb D-type impact device for PCE Instruments PCE-900 hardness tester, black-silver with blue cable
PCE Instruments PCE-900 portable Leeb rebound hardness tester with large LCD display and control buttons
PCE Instruments PCE-900 portable Leeb rebound hardness tester in use, probe on a metal shaft
Technician using PCE Instruments PCE-900 portable Leeb rebound hardness tester on a metal bar in a workshop
PCE Instruments PCE-900 portable Leeb rebound hardness tester in use on a metal surface, with probe cable
PCE data acquisition system for ultrasonic thickness gauge, with display unit and PC software screenshots
PCE-900 portable Leeb rebound hardness tester with LCD display, keypad and cabled impact device, with calibration certificate...

Availability & price

Code Range Availability excl. VATincl. VAT Certificate Cart
PCE-900 200 ... 900 HLD
€890,00
€1.103,60
0
  • Leeb rebound hardness tester
  • 9 metals pre-calibrated
  • 6 hardness scales
  • Type D impact probe
  • Memory for 50 readings

The PCE-900 is a portable Leeb hardness tester for nine different metals. A firing pin strikes the metal surface and the intensity of the rebound indicates the material hardness. Readings are shown in six hardness scales: Rockwell B and C, Brinell, Vickers, Shore and Leeb.

The tester is supplied with a type D impact probe as standard. Optional software transfers the readings live to a PC. It is used for material inspection and incoming goods control.

Highlights

  • Hardness testing by Leeb rebound method
  • 9 pre-calibrated materials
  • 6 hardness scales: HRC, HRB, HB, HV, HSD, HL
  • Type D impact probe included
  • Internal memory for 50 data records
  • Data interface with optional PC software
  • Backlit 2 inch LCD
Hardness
Measuring range200 ... 900 HL
Resolution1 HL
Accuracy±0.8% with HLD =900
General technical data
Display typeLCD with backlight
Display size2 Inch
Storage mediumInternal memory
Storage capacity50 Data records
MaterialsCast steel, Stainless steel, Grey cast iron, Spheroidal graphite cast iron, Brass, Bronze, Copper, Cast aluminium, Cold work steel
Automatic power-off3 min
Impact deviceD-type
Hardness scalesHRC, HRB, HB, HV, HSD, HL
(Rechargeable) battery3 x 1,5 V AAA battery , Alkali-manganese
Capacity1200 mAh
Performance1,8 Wh
Operating conditions-10 ... 50 °C , 0 ... 90 % RH
Storage conditions-30 ... 60 °C , 0 ... 90 % RH
Dimensions ( L x W x H )142 x 77 x 40 mm
Weight130 g
Other weightsImpact device: 75 g
  • 1×Leeb Hardness Tester PCE-900
  • 1×Impact probe Type D
  • 1×Test block
  • 1×Support ring
  • 1×Cleaning brush
  • 1×Carrying case
  • 1×User manual
Datasheet Technical datasheet Manual User manual
