Shore Durometers

Availability & price

2 codes

Code Range Type Application Availability excl. taxes Certificate Cart
PCE-DD-A 0-100 HA Type A for soft
€119,00
0
PCE-DD-D 0-100 HD Type D for hard
€119,00
0

Description

  • Shore A or Shore D hardness
  • Range 0 ... 100 Shore A/D
  • Resolution 0.5 degrees of hardness
  • Accuracy ± 2 hardness grades
  • Large, easy-to-read digital display

The durometer is a handheld digital device. It tests the Shore hardness of rubber, plastics and other non-metallic materials. The Shore A version (PCE-DD-A) is for soft rubber, elastomers, natural rubber, neoprene, casting resin, white PVC and leather. The Shore D version (PCE-DD-D) is for hard rubber, hard resin, acrylic, glass and thermoplastics.

A conical indenter presses into the surface with a test force of 12,5 N (Shore A) or 50 N (Shore D). Samples must be at least 6 mm (0.24 in) thick. Back thinner samples with more of the same material.

Highlights

  • Handheld, portable digital device
  • Hold function
  • Test force 12,5 N (Shore A) / 50 N (Shore D)
  • Minimum sample thickness 6 mm (0.24 in)
  • Plastic carrying case included

Specifications

General technical data
Measuring functionsHOLD
Impact deviceD-type
Measuring depth0 ... 2.5 mm
Sample thicknessmin. 6 mm
Menu languageEnglish, English (GB)
Protection class (device)IP20
Power supplybatteries
Battery1 x 1,5 V LR44 , Alkali-manganese
Battery capacity140 mAh
Operating conditions0 ... 50 °C , 0 ... 90 % RH
Storage conditions0 ... 50 °C , 0 ... 90 % RH
Weight300 g

Differences by model

PCE-DD-APCE-DD-D
Resolution0,5 Shore A0,5 Shore D
Accuracy±2 Shore A±2 Shore D
Indenter35°30°
Test force12,5 N50 N
Dimensions ( L x W x H )115 x 60 x 25 mm85 x 60 x 25 mm

Package Contents

  • 1×Durometer
  • 1×Plastic carrying case
  • 1×Battery
  • 1×User manual
