K-Type Surface Thermocouple -75..250 °C

Specifications

• Thermocouple type: K
• Sensor: flat ribbon, 15 × 130 mm
• Temperature range: -75°C ~ 250°C
• Accuracy: ±1.5°C (-40°C ~ 375°C)
• Response time: under 0.5 seconds
• Standard: BS EN 60584-1:2013
• Connection: type K plug

Description

Type K surface thermocouple with a flat ribbon sensor. The ribbon sits against the surface across its full width, rather than touching at a single point like a rounded tip. Contact is better, heat loss is lower, and the reading stays closer to the surface's true temperature.

That construction gives a response time of under half a second, among the fastest of any surface probe, across a -75°C to 250°C range.

A 90° angled version and a coiled lead are available to order.

• Pipe temperature checks, HVAC and legionella prevention
• Measurements on flat surfaces and plates
• Applications needing very fast response
